Motor para porta de elevador KM87147G01 200 V CC, 1 A, 200 W para Kone

Descrição

Informações sobre o produto

Modelos relacionados e alternativos

Other Kone door motors:

• KM601370G03 — AMD door motor, left opening
• KM601370G04 — AMD door motor, right opening
• KM602748G03 — AMD 1.5 / MIDI door motor
• KM903370G04 — door motor, 36 V, 4000 rpm

ADF and ADX operator parts:

• KM88998G01 — ADX/ADF drive control unit
• KM60365G01 — ADF/ADM/ADR door motor

Potensi supplies the Kone elevator door motor KM87147G01, the Kone ADF and ADX door operator motor and other Kone door parts. The models above are only a part of what we can supply. We stock and source a much wider range of related and alternative models. If your model number is not listed here, please send us the model number or a photo of the original part, and we will confirm availability and the correct match for you.

Porquê escolher a Potensi?

• Cobertura de mercado do 99%: Podemos fornecer cerca de 99% de peças sobressalentes para elevadores disponíveis no mercado.
• Garantia de Qualidade Autêntica: Fornecemos componentes para elevadores originais e fiáveis.
• Apoio à identificação por peritos: Envie-nos o número do modelo ou fotografias do produto e poderemos ajudá-lo a identificar a peça correta.
• Envio internacional: Oferecemos um serviço de entrega internacional rápido e fiável para projetos de manutenção de elevadores.

Perguntas frequentes

Q1: Which Kone doors does this motor drive?

R: Kone lists KM87147G01 for the ADF door and for the ADX 1 and ADX 2 doors. Its ratings are 200 V DC, 1 A, 200 W and 7600 rpm. It is the motor of the door operator, so it drives the panels; it is not the board that controls them.

Q2: Does the motor come with the tachogenerator?

R: Yes, the tacho is built onto the motor, and Kone describes the part as a motor with tacho for the ADF and ADX operators. The tacho tells the operator how fast the door is moving, so its leads have to be reconnected in the same order as on the old motor. If the two tacho wires are swapped, the door will run away or hunt instead of following the speed curve.

Q3: Is KM88998G01 the same thing?

R: No, KM88998G01 is the ADX/ADF drive control unit, the board that powers and controls the motor. This page is for the motor only, and a complete door repair often needs both. Please describe the fault: a door that does not move at all and a door that moves at the wrong speed do not point to the same part.

Q4: Will an AMD door motor fit instead?

R: No, the AMD motors are a different range with different mountings and gearboxes. Typical AMD references are KM601370G03 for left opening and KM601370G04 for right opening, with KM602748G03 for the AMD 1.5 / MIDI operator. Compare the nameplate and the shaft end of your old motor with the photo before ordering.

Q5: What should be checked before fitting a new motor?

R: Check that the door runs freely by hand and that the belt or rope is not seized, because a stiff door overloads a new motor. Check the supply from the door control unit, and check that the tacho wiring is intact along the travelling cable. Please send a photo of the old motor and its label, and the operator type, so we confirm the correct version.

Q6: Do you supply other Kone door parts?

R: Yes, we supply the ADF and ADX door motors, the drive control unit and other Kone door operator parts. The Kone range is large, so the fastest way is to send the KM number or a photo of the label. We confirm availability and the correct match before shipping.
