Description
MGT8012XB-R38 is a high-performance DC axial cooling fan designed for demanding industrial applications, including elevator control cabinets, UPS systems, inverters, and power supplies. Series F variant typically incorporates PWM speed control, enabling intelligent thermal management—delivering maximum airflow under high heat loads and reducing speed for energy efficiency when cooling demands are lower.
Fan MGT8012XB-R38 Parameters
| Dimensions (mm) | 80 × 80 | Type | Axial |
| Voltage Type | DC | Voltage (V) | 12 |
| Current (A) | 1.2 | Power (W) | 14.4 |
| Speed (RPM) | 6300 | Noise (dB) | 53.5 |
| Thickness (mm) | 38 | Bearing | Dual Ball |
| Airflow (m³/min) | 2.488 | Airflow (CFM) | 87.83 |
| Static Pressure (Pa) | 21.2 | Static Pressure (inchH₂O) | 0.835 |
| Model | MGT8012XB-R38 |
Fan MGT8012XB-R38 Detail
| Bearing Type | 2 Ball |
| Speed Control | Voltage, PWM, ±10% Speed Tolerance |
| Frame Type | 8 Screw |
| Signal Output | Alarm Signal, Tacho Signal |
| Protection | Lock, Reverse |
| ESD | Class III |
| Insulation | Class A |
| Safety | UL, TUV, CE |
| Motor Type | Uni-phase |



Why Choose Potensi?
Potensi provides high-quality Elevator Fan MGT8012XB-R38 F DC12V 2.8A, engineered to deliver exceptional reliability and performance for modern elevator systems. As a trusted supplier of Elevator Fan, we offer a wide range of products, including specialized options like Elevator Fan, ensuring compatibility with top global brands such as Mitsubishi, Otis, Thyssen, Hyundai, and others. With ample stock and competitive pricing, Potensi is ready to meet your needs. CONTACT Esther today—Potensi looks forward to helping you enhance your elevator systems!
